3.2 Location of safety signs
The safety signs are located in the following machine positions:
Fig. 3-1 Locations of safety signs
1 Safety distance (left and right sides of lifting frame)
2 Safety distance
3 Danger of injury
4 Danger of crushing
4
1
2
3
