5 Description of the Wheel Loader
5.1 Overview of wheel loader
Fig. 5-1 Overview of wheel loader
1 Bucket
2 Quick-attach system
3 Lifting frame
4 Front-end
5 Cab
6 Door catch
7 Engine
8 Articulation
9 Type label
10 Battery
11 Fuel tank
12 Hydraulic oil tank
13 Radiator and hydraulic oil cooler
2
5
7
4
8
9
10
12
11
3
6
1
13
