5.1.1 Overview filters
Fig. 5-2 Overview filters
1 Air filter
2 Fuel filter
3 Engine oil filter
4 Return filter Hydraulic oil tank
5 Suction filter Hydraulic oil tank
6 Breather filter Hydraulic oil tank
3
2
1
4
6
5
4560_5002
