TL260
Maintenance
70 / 187
6
06_Maintenance_en.fm - V 0.1 - 14.4.11
11
6.7.3 Engine - cooling system
Combined hydraulic oil-water cooler
Checking the coolant level
Fig. 6-10 Checking the coolant level
The coolant level is monitored automatically.
If the coolant level is insufficient, the coolant level indicator appears on the
display as soon as the ignition is switched on. (1).
Top up coolant if the coolant level is insufficient.
Danger of burning
Danger of scalding by hot oil.
Z Only open the radiator cap
when the engine is cold.
Z Wear suitable protective
clothing and safety goggles.
12 km/h
I
1
4560_6009
