Terex TL260 - Page 161

TL260
Specifications
09_Specifications_en.fm - V 0.1 - 14.4.11
159 / 187
9
17
9.1.3 Dimensioned drawing with light-material bucket and quick-
attach system
Fig. 9-3 Dimensioned drawing with light-material bucket and quick-attach system and tires 20.5 R 25
4560_9003
3100 1684
35°
620
4040
40°
80°
R3060
1900
2500
2350
11 7 °
1330
2670
51°
120
45°
7350
R6210
3260
