TL260
Maintenance
88 / 187
6
06_Maintenance_en.fm - V 0.1 - 14.4.11
11
Changing the hydraulic oil
Retract all hydraulic cylinders.
Stop the engine.
Remove the drain plug on the hydraulic oil tank and drain oil into a clean
receptacle.
Remove ventilation filter (2), return filter (3) with filter head and suction
filter (4).
Clean filter head.
Fit new filter.
Turn the drain plug tightly back in.
Fill up with clean hydraulic oil using the return filter (3); to do so, open the filter
cover.
Replace the cover of the return filter.
Fig. 6-26 Changing the hydraulic oil
Danger of burning
Danger of scalding by hot oil.
Z Be careful when draining hot
oil.
Z Wear suitable protective
clothing and safety goggles.
Note
Collect the waste oil in a suitable container and dispose of in compliance
with regulations.
