6 Using the product
112
Designation Explanation
[OK] Applies the settings until other data are
called up. The dialogue is closed.
[Cancel] Closes the dialogue without applying any
changes.
Position Shows a freely-definable extract of the
diagram.
Autom. scaling...
Shows the entire diagram in the window.
Extract Shows a fixed, defined extract that can be
moved over the time axis.
Limits from ... to (if
Position view is
activated)
Limits for the Position view.
Minimum time
cycle (if Extract
view is activated)
Specification of which time period should
at least be shown.
Selection list for
the unit (if Extract
view is activated)
Unit of the time axis in the minimum time
cycle:
• sec (second)
• min (minute)
• h (hour)
• d (day).
Absolute All times are the real times at which the
readings were recorded.
Relative Sets the starting time to 00:00; the time
the runs relative to this starting point.
Paging enabled The function associated with this is not
available in the Small Business Edition.
Division Automat. Specification that the program should
perform the division of the axis.
Division Manual Specification that the division of the axis
should be performed manually.
Grid [<], [>] (if
automatic division is
activated)
Decrease or increase the division of the
axis by clicking on [<] or [>].
Interval (if manual
division is activated)
Manual entry of the grid.
