5 First steps
83
Pos: 87 /TD/Erst e Schritte/testo Saver is/07 **** Montage der Hard ware/03 Fühler montier en @ 0\mod_1189157541812 _79.docx @ 4114 @ 3 @ 1
5.13.3. Mounting the probe on the wall
When selecting the location, take into account the
following points:
• The range of the probe may not be exceeded; see
Connecting radio probe, page 37 and see
Performing the test run, page 77
• Attach the probe in such a way that the readings
cannot be distorted, e.g. by exposure to direct
sunlight
The mounting materials (screws, anchor plugs etc.) are
not included in the delivery.
1. Position wall bracket at the desired location.
2. Using a pen, mark the locations for the fastening screws.
The distance between the fastening screws is 30 mm.
3. Prepare the fastening location for the attachment in accordance
with the material (e.g. drill hole, insert anchor plug).
4. Fasten wall bracket using appropriate screws.
The wall bracket must be screwed down with the
smooth surface facing the wall.
