5 First steps
80
Pos: 85 /TD/Erst e Schritte/testo Saver is/07 **** Montage der Hard ware/01 Base an der Wand mon tieren @ 0\mod_1189157492 531_79.docx @ 4105 @ 3 @ 1
5.13.1. Mounting the Saveris base on the wall
When selecting the location for the Saveris base,
please take into account that this must be positioned
close enough to the computer used and a possible
power supply in accordance with the cabling provided.
The mounting materials (screws, anchor plugs etc.) are
not included in the delivery.
1. Position wall bracket at the desired location.
2. Using a pen, mark the locations for the fastening screws.
The distance between the fastening screws is 25 mm.
3. Prepare the fastening location for the attachment in accordance
with the material (e.g. drill hole, insert anchor plug).
4. Fasten wall bracket using appropriate screws.
