5 First steps
35
Pos: 54 /TD/Erst e Schritte/testo Saver is/02b-1 Stromver sorgung über AC/DC verbinde n @ 0\mod_1191328406187_7 9.docx @ 5402 @ 3 @ 1
5.5.2. Power supply via plug-in/screw connection
(optional)
Pos: 55 /TD/Erste Sc hritte/testo Saveris/02b- 2 SBE Stromversorgung über AC /DC verbinden @ 1\mod_1202124 389613_79.doc x @ 8067 @ @ 1
Pos: 56 /TD/Erst e Schritte/testo Saver is/02b-3 Stromver sorgung über AC/DC verbinde n @ 1\mod_1202124473316_7 9.docx @ 8089 @ @ 1
1. Loosen clamping screws no. 1 and no. 2.
2. Insert cable in the terminals as shown.
Observe permissible operating voltage!
3. Tighten clamping screws.
4. Ensure that cabling cannot be pulled out using a cable tie at the
eyelets for strain relief .
5. Place the cover on the Saveris base and screw it down .
- The Saveris base automatically switches on after selecting the
language at the base and is ready for operation.
