4 Product description
28
Pos: 41 /TD/Produk tbeschreibung/ Übersicht/testo Saver is/05 Analogkoppler /01 Analogkoppler @ 4\ mod_1245762445743_79. docx @ 45338 @ 2 @ 1
4.7. Saveris analog coupler
Only with radio analog coupler U1: Antenna for sending the
measurement data.
LED for status display.
Connect button for connecting the analog coupler to the Saveris
base and for a status request during operation.
Catch for the wall bracket.
Guide rails for the wall bracket.
Cable coupling M16 x 1.5 for connecting to the transmitter.
Only with Ethernet analog coupler U1E: Input for connecting the
network cable.
Input for service interface.
Input for power supply via mains unit.
