TESTO Saveris T1E Ethernet probe User Manual

6 Using the product
127
Designation Explanation
data
of the probe from the adjustment
software.
Display
adjustment data
Button for displaying the adjustment data
of the probe that has already been
imported.
Pos: 161 /TD/Produ kt verwenden/testo Sa veris/09 Einstellu ngen System/07 Analog koppler @ 4\mod_1248704611 882_79.docx @ 46423 @ 2 @ 1
6.9.5. Analog coupler
Via this menu item you can change the power supply of the analog
coupler or reset a sum channel, for example.
With the radio analog coupler U1 the same information is shown
under the Radio probe setting entry as with the radio probe (see
Settings for the radio probe page 123).
With the Ethernet analog coupler U1E the same information is
shown under the Ethernet probe setting entry as with the
Ethernet probe (see Ethernet probes page 125).
1. Open the Radio probe| Ethernet probe > Scaling entry.
- The settings of the selected probe are shown in the display
range.
Designation Explanation
Connection
Output signal of the transmitter.
Display
Display range of the physical unit.
