7 Maintaining the product
145
freezer applications (for operation below -10°C).
You can check the battery status of the probes via the
Saveris software. Under System | Radio probe, select the
probe you want to test. The current charge status is
displayed in the Battery status field.
> Remove probe from the wall mount; see "Removing probe
from wall bracket".
The probe must be at room temperature when the battery is
changed, otherwise a build-up of moisture may impair the
measuring accuracy.
1. Undo screws on the back of the probe.
2. Remove the probe housing cover .
3. Change batteries .
Ensure that you insert the batteries correctly.
The correct polarity is illustrated in the respective
battery compartment.
4. Refit the probe housing cover.
5. Screw the cover tightly on to the housing.
A control switch is located in the housing that is
actuated through the cover. To do so, the cover must be
