TEXA eLight ONE - Page 29

3. Tighten the screws with a torque
of 12 Nm.
4. Fasten the optical box to the
specific support from above and
then rotate it as illustrated.
5. Secure the optical box to the
support by tightening the specific
screws with a torque of 3 Nm.
75
en
