AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
PRU0
PRU0/General Purpose Inputs Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_pru0_pru_r31_0 PRU0 Data In I NA A13
pr1_pru0_pru_r31_1 PRU0 Data In I NA B13
pr1_pru0_pru_r31_10 PRU0 Data In I H17 G15
pr1_pru0_pru_r31_11 PRU0 Data In I G18 G16
pr1_pru0_pru_r31_12 PRU0 Data In I G19 G17
pr1_pru0_pru_r31_13 PRU0 Data In I G17 G18
pr1_pru0_pru_r31_14 PRU0 Data In I W17 V13
pr1_pru0_pru_r31_15 PRU0 Data In I V17 U13
pr1_pru0_pru_r31_16 PRU0 Data In Capture Enable I B15, C19 D14, D15
pr1_pru0_pru_r31_2 PRU0 Data In I NA D12
pr1_pru0_pru_r31_3 PRU0 Data In I NA C12
pr1_pru0_pru_r31_4 PRU0 Data In I NA B12
pr1_pru0_pru_r31_5 PRU0 Data In I NA C13
pr1_pru0_pru_r31_6 PRU0 Data In I NA D13
pr1_pru0_pru_r31_7 PRU0 Data In I NA A14
pr1_pru0_pru_r31_8 PRU0 Data In I H19 F17
pr1_pru0_pru_r31_9 PRU0 Data In I H18 F18
PRU0/General Purpose Outputs Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_pru0_pru_r30_0 PRU0 Data Out O NA A13
pr1_pru0_pru_r30_1 PRU0 Data Out O NA B13
pr1_pru0_pru_r30_10 PRU0 Data Out O H17 G15
pr1_pru0_pru_r30_11 PRU0 Data Out O G18 G16
pr1_pru0_pru_r30_12 PRU0 Data Out O G19 G17
pr1_pru0_pru_r30_13 PRU0 Data Out O G17 G18
pr1_pru0_pru_r30_14 PRU0 Data Out O U13 T12
pr1_pru0_pru_r30_15 PRU0 Data Out O T13 R12
pr1_pru0_pru_r30_2 PRU0 Data Out O NA D12
pr1_pru0_pru_r30_3 PRU0 Data Out O NA C12
pr1_pru0_pru_r30_4 PRU0 Data Out O NA B12
pr1_pru0_pru_r30_5 PRU0 Data Out O NA C13
pr1_pru0_pru_r30_6 PRU0 Data Out O NA D13
pr1_pru0_pru_r30_7 PRU0 Data Out O NA A14
pr1_pru0_pru_r30_8 PRU0 Data Out O H19 F17
pr1_pru0_pru_r30_9 PRU0 Data Out O H18 F18
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 67
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
