AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
PRU1
PRU1/General Purpose Inputs Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_pru1_pru_r31_0 PRU1 Data In I U1 R1
pr1_pru1_pru_r31_1 PRU1 Data In I U2 R2
pr1_pru1_pru_r31_10 PRU1 Data In I W5 V5
pr1_pru1_pru_r31_11 PRU1 Data In I W7 R6
pr1_pru1_pru_r31_12 PRU1 Data In I V14 U9
pr1_pru1_pru_r31_13 PRU1 Data In I U15 V9
pr1_pru1_pru_r31_14 PRU1 Data In I E19 E15
pr1_pru1_pru_r31_15 PRU1 Data In I F17 E16
pr1_pru1_pru_r31_16 PRU1 Data In Capture Enable I C15, D18 A15, D16
pr1_pru1_pru_r31_2 PRU1 Data In I V1 R3
pr1_pru1_pru_r31_3 PRU1 Data In I V2 R4
pr1_pru1_pru_r31_4 PRU1 Data In I W2 T1
pr1_pru1_pru_r31_5 PRU1 Data In I W3 T2
pr1_pru1_pru_r31_6 PRU1 Data In I V3 T3
pr1_pru1_pru_r31_7 PRU1 Data In I U3 T4
pr1_pru1_pru_r31_8 PRU1 Data In I U7 U5
pr1_pru1_pru_r31_9 PRU1 Data In I T7 R5
PRU1/General Purpose Outputs Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
pr1_pru1_pru_r30_0 PRU1 Data Out O U1 R1
pr1_pru1_pru_r30_1 PRU1 Data Out O U2 R2
pr1_pru1_pru_r30_10 PRU1 Data Out O W5 V5
pr1_pru1_pru_r30_11 PRU1 Data Out O W7 R6
pr1_pru1_pru_r30_12 PRU1 Data Out O V14 U9
pr1_pru1_pru_r30_13 PRU1 Data Out O U15 V9
pr1_pru1_pru_r30_14 PRU1 Data Out O E19 E15
pr1_pru1_pru_r30_15 PRU1 Data Out O F17 E16
pr1_pru1_pru_r30_2 PRU1 Data Out O V1 R3
pr1_pru1_pru_r30_3 PRU1 Data Out O V2 R4
pr1_pru1_pru_r30_4 PRU1 Data Out O W2 T1
pr1_pru1_pru_r30_5 PRU1 Data Out O W3 T2
pr1_pru1_pru_r30_6 PRU1 Data Out O V3 T3
pr1_pru1_pru_r30_7 PRU1 Data Out O U3 T4
pr1_pru1_pru_r30_8 PRU1 Data Out O U7 U5
pr1_pru1_pru_r30_9 PRU1 Data Out O T7 R5
68 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
