AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
Removable Media Interfaces
Removable Media Interfaces/MMC0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
mmc0_clk MMC/SD/SDIO Clock I/O G19 G17
mmc0_cmd MMC/SD/SDIO Command I/O G17 G18
mmc0_dat0 MMC/SD/SDIO Data Bus I/O G18 G16
mmc0_dat1 MMC/SD/SDIO Data Bus I/O H17 G15
mmc0_dat2 MMC/SD/SDIO Data Bus I/O H18 F18
mmc0_dat3 MMC/SD/SDIO Data Bus I/O H19 F17
mmc0_dat4 MMC/SD/SDIO Data Bus I/O N16 L16
mmc0_dat5 MMC/SD/SDIO Data Bus I/O N17 L17
mmc0_dat6 MMC/SD/SDIO Data Bus I/O M19 L18
mmc0_dat7 MMC/SD/SDIO Data Bus I/O N19 K18
mmc0_pow MMC/SD Power Switch Control O B16, K18 C15, H18
mmc0_sdcd SD Card Detect I B16, P17 A13, C15, M17
mmc0_sdwp SD Write Protect I E18, R19 B12, C18, M18
Removable Media Interfaces/MMC1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
mmc1_clk MMC/SD/SDIO Clock I/O L18, R19, V14 K17, M18, U9
mmc1_cmd MMC/SD/SDIO Command I/O M18, P17, U15 K16, M17, V9
mmc1_dat0 MMC/SD/SDIO Data Bus I/O N19, V15, W10 K18, U10, U7
mmc1_dat1 MMC/SD/SDIO Data Bus I/O M19, V9, W16 L18, T10, V7
mmc1_dat2 MMC/SD/SDIO Data Bus I/O N17, T12, V12 L17, R8, T11
mmc1_dat3 MMC/SD/SDIO Data Bus I/O N16, U12 , W13 L16, T8, U12
mmc1_dat4 MMC/SD/SDIO Data Bus I/O U13, V13 T12, U8
mmc1_dat5 MMC/SD/SDIO Data Bus I/O T13, W14 R12, V8
mmc1_dat6 MMC/SD/SDIO Data Bus I/O U14, W17 R9, V13
mmc1_dat7 MMC/SD/SDIO Data Bus I/O V17, W15 T9, U13
mmc1_sdcd SD Card Detect I R15 B13, T17
mmc1_sdwp SD Write Protect I B17, D18 B16, D16
Removable Media Interfaces/MMC2 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
mmc2_clk MMC/SD/SDIO Clock I/O P19, R19, V16 L15, M18, V12
mmc2_cmd MMC/SD/SDIO Command I/O K17, P17, U17 J16, M17, T13
mmc2_dat0 MMC/SD/SDIO Data Bus I/O L19, U13 J17, T12, V14
mmc2_dat1 MMC/SD/SDIO Data Bus I/O M17, T13 J18, R12, U14
mmc2_dat2 MMC/SD/SDIO Data Bus I/O N18, W17 K15, T14, V13
mmc2_dat3 MMC/SD/SDIO Data Bus I/O J19, V17, V18 H16, U13, U18
mmc2_dat4 MMC/SD/SDIO Data Bus I/O V15 U10, U15
mmc2_dat5 MMC/SD/SDIO Data Bus I/O W16 T10, T15
mmc2_dat6 MMC/SD/SDIO Data Bus I/O T12 T11, V16
mmc2_dat7 MMC/SD/SDIO Data Bus I/O U12 U12
mmc2_sdcd SD Card Detect I W18 D12, U17
mmc2_sdwp SD Write Protect I A17, C19 A16, D15
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 69
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
