Page #87 background imageLoading...
Page #87 background image
www.ti.com
I/O Registers
The selected 32-kHz clock source can be output on one of the P0 pins. The enable bit CKOEN enables the
output on P0, and the pin of P0 is selected using the CKOPIN (see the PMUX register description for
details). When CKOEN is set, all other configurations for the selected pin are overridden. The clock is
output in all power modes; however, in PM3 the clock stops (see PM3 in Chapter 4).
Furthermore, the digital regulator status can be output on one of the P1 pins. When the DREGSTA bit is
set, the status of the digital regulator is output. DREGSTAPIN selects the P1 pin (see the PMUX register
description for details). When DREGSTA is set, all other configurations for the selected pin are overridden.
The selected pin outputs 1 when the 1.8-V on-chip digital regulator is powered up (chip has regulated
power). The selected pin outputs 0 when the 1.8-V on-chip digital regulator is powered down, i.e., in PM2
and PM3.
7.11 I/O Registers
The registers for the I/O ports are described in this section. The registers are:
P0: Port 0
P1: Port 1
P2: Port 2
PERCFG: Peripheral-control register
APCFG: Analog peripheral I/O configuration
P0SEL: Port 0 function-select register
P1SEL: Port 1 function-select register
P2SEL: Port 2 function-select register
P0DIR: Port 0 direction register
P1DIR: Port 1 direction register
P2DIR: Port 2 direction register
P0INP: Port 0 input-mode register
P1INP: Port 1 input-mode register
P2INP: Port 2 input-mode register
P0IFG: Port 0 interrupt-status flag register
P1IFG: Port 1 interrupt-status flag register
P2IFG: Port 2 interrupt-status flag register
PICTL: Interrupt edge register
P0IEN: Port 0 interrupt-mask register
P1IEN: Port 1 interrupt-mask register
P2IEN: Port 2 interrupt-mask register
PMUX: Power-down signal-mux register
OBSSEL0: Observation output control register 0
OBSSEL1: Observation output control register 1
OBSSEL2: Observation output control register 2
OBSSEL3: Observation output control register 3
OBSSEL4: Observation output control register 4
OBSSEL5: Observation output control register 5
P0 (0x80) Port 0
Bit Name Reset R/W Description
7:0
P0[7:0]
0xFF R/W Port 0. General-purpose I/O port. Bit-addressable from SFR. This CPU-internal register is readable,
but not writable, from XDATA (0x7080).
87
SWRU191CApril 2009Revised January 2012 I/O Ports
