www.ti.com
EVM User Setup/Configuration
17
SPRUIS4A–December 2019–Revised May 2020
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Jacinto7 J721E/DRA829/TDA4VM Evaluation Module (EVM)
Test points for each system power rails are provided on the Common Processor Board (CPB) and are
mentioned in Table 5. Location for each can be identified by searching the assembly drawing for the test
point reference number.
Table 5. Power Test Points
Power Supply Test Point Nominal Voltage
VINPUT TP20 12.0V
VSYS_3V3 TP130 3.3V
VCC_12V0 TP39 12.0V
VSYS_5V0 TP26 5.0V
EXP_3V3 TP43 3.3V
VDD_2V5 TP63 2.5V
VDD_1V0 TP59 1.0V
VCC_1V1 TP60 1.1V
VSYS_MCU_5V0 TP117 5.0V
VDD_SD_DV TP44 3.3V
VSYS_MCUIO_3V3 TP113 3.3V
VSYS_IO_3V3 TP131 3.3V
VSYS_MCUIO_1V8 TP134 1.8V
VSYS_IO_1V8 TP132 1.8V
VDA_MCU_1V8 TP105 1.8V
