www.ti.com
J721E EVM Hardware Architecture
75
SPRUIS4A–December 2019–Revised May 2020
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Jacinto7 J721E/DRA829/TDA4VM Evaluation Module (EVM)
Table 44 and Table 45 lists the EVM expansion connectors pinouts.
Table 44. EVM Expansion Connector J46 Pinout
INFO/GESI Connector Interface J46
Pin No Signal Pin No Signal
1 DGND 2 VCC_12V0
3 DGND 4 VCC_12V0
5 DGND 6 VCC_12V0
7 MCASP1_AXR3/PRG0_RGMII2_RXC 8 VOUT0_DATA15/PRG1_RGMII2_TX_CTL
9 PRG0_RGMII2_RD3 10 VOUT0_DATA14/PRG1_RGMII2_TD3
11 MCASP1_AXR2/PRG0_RGMII2_RX_CTL 12 VOUT0_HSYNC/PRG1_RGMII2_TXC
13 MCASP1_AXR0/PRG0_RGMII2_RD0 14 VOUT0_DATA11/PRG1_RGMII2_TD0
15 MCASP1_AXR1/PRG0_RGMII2_RD1 16 VOUT0_DATA13/PRG1_RGMII2_TD2
17 PRG0_RGMII2_RD2 18 VOUT0_DATA12/PRG1_RGMII2_TD1
19 DGND 20 DGND
21 VOUT0_EXTPCLKIN/MCAN6_TX 22 VPFE0_DATA6/MCAN5_TX
23 VOUT0_DATA5/MCAN6_RX 24 VPFE0_DATA7/MCAN5_RX
25 VOUT0_DATA7/MCAN7_TX 26 AUDIO_EXT_REFCLK1/MCAN4_TX
27 VOUT0_DATA8/MCAN7_RX 28 VOUT0_DATA22/MCAN4_RX
29 VOUT0_DATA9/PRG1_UART0_RXD 30 PRG1_UART0_RTS#
31 VOUT0_DATA10/PRG1_UART0_TXD 32 VOUT0_DATA23/SPI6_CS1
33 VOUT0_VSYNC/SPI6_D0 34 VOUT0_DE/SPI6_CLK
35 NC 36 VOUT0_PCLK/SPI6_D1
37 DGND 38 DGND
39 VOUT0_DATA0/PRG1_RGMII2_RD0 40 VOUT0_DATA19/PRG1_RGMII1_TD3
41 VOUT0_DATA2/PRG1_RGMII2_RD2 42 VOUT0_DATA16/PRG1_RGMII1_TD0
43 VOUT0_DATA1/PRG1_RGMII2_RD1 44 VOUT0_DATA20/PRG1_RGMII1_TX_CTL
45 VOUT0_DATA3/PRG1_RGMII2_RD3 46 VOUT0_DATA18/PRG1_RGMII1_TD2
47 VOUT0_DATA4/PRG1_RGMII2_RX_CTL 48 VOUT0_DATA21/PRG1_RGMII1_TXC
49 VOUT0_DATA6/PRG1_RGMII2_RXC 50 VOUT0_DATA17/PRG1_RGMII1_TD1
51 DGND 52 DGND
53 MCASP0_AXR5/MCAN9_TX 54 VPFE0_DATA12/PRG1_MDIO0_MDC
55 MCASP0_AXR6/MCAN9_RX 56 VPFE0_DATA11/PRG1_MDIO0_MDIO
57 MCASP0_ACLKX/SPI3_CS1 58 SPI3_CS0
59 MCASP0_AFSX/SPI3_CS2 60 MCASP1_AFSX/MCAN11_RX
61 McASP0_AXR3 62 NC
63 WKUP_I2C0_SDA 64 SOC_PORZ_OUT
65 WKUP_I2C0_SCL 66 PRG0_PWM0_TZ_OUT
67 DGND 68 DGND
69 MCASP0_AXR0/PRG0_RGMII1_RD0 70 MCASP0_AXR8/PRG0_RGMII1_TD1
71 MCASP0_AXR2/PRG0_RGMII1_RX_CTL 72 MCASP0_AXR7/PRG0_RGMII1_TD0
73 MCASP0_AXR4/PRG0_RGMII1_RXC 74 MCASP0_AXR11/PRG0_RGMII1_TX_CTL
75 PRG0_RGMII1_RD2 76 MCASP0_AXR10/PRG0_RGMII1_TD3
77 MCASP0_AXR1/PRG0_RGMII1_RD1 78 MCASP0_AXR9/PRG0_RGMII1_TD2
79 PRG0_RGMII1_RD3 80 MCASP0_AXR12/PRG0_RGMII1_TXC
81 DGND 82 DGND
83 MCASP1_AXR8/PRG0_RGMII2_TD1 84 MCASP6_ACLKX/PRG1_RGMII1_RD0
85 MCASP1_AXR7/PRG0_RGMII2_TD0 86 MCASP6_AFSR/PRG1_RGMII1_RXC
87 GPIO0_79/PRG0_RGMII2_TXC 88 MCASP6_AFSX/PRG1_RGMII1_RD1
89 PRG0_RGMII2_TD2 90 PRG1_RGMII1_RD3
