Jacinto7 J721E/DRA829/TDA4VM Evaluation Module (EVM)
4.5.3.3 Power Monitoring
INA226 power monitor devices are used to monitor current and voltage of various power rails of J721E
processor. The device reports current, voltage and power to J721E processor through I2C interface. Four
Terminal High Precision shunt resistors are provided, and the values are calculated based on load current.
Table 22. INA Devices I2C Slave Address
Power Source Supply Net I2C Bus
Slave Address
(IN HEX)
Value of the Shunt
Connected to the
Supply Rail
VDD_MCU_0V85_REG VDD_MCU_0V85 SOC_I2C2/PM1 0x40 0.01E
VDD_MCU_RAM_0V85_REG VDD_MCU_RAM_0V85 SOC_I2C2/PM1 0x41 0.01E
VDA_MCU_1V8_REG VDA_MCU_1V8 SOC_I2C2/PM1 0x42 0.01E
VDD_MCUIO_3V3_LS VDD_MCUIO_3V3 SOC_I2C2/PM1 0x43 0.01E
VDD_MCUIO_1V8_REG VDD_MCUIO_1V8 SOC_I2C2/PM1 0x44 0.01E
VDD_CORE_0V8_REG VDD_CORE_0V8 SOC_I2C2/PM1 0x45 0.01E
VDD_CORE_RAM_0V85_REG VDD_CORE_RAM_0V85 SOC_I2C2/PM1 0x46 0.01E
VDD_CPU_RAM_0V85_REG VDD_CPU_RAM_0V85 SOC_I2C2/PM1 0x47 0.01E
VDD_CPU_AVS_REG VDD_CPU_AVS SOC_I2C2/PM1 0x48 0.01E
V917_SMPS3_1V1 VDDR_BIAS_1V1 SOC_I2C2/PM1 0x49 0.01E
VDDR_IO_DV_SRC VDDR_IO_DV SOC_I2C2/PM1 0x4A 0.01E
VDD_CORE_0V8_REG VDD_PHYCORE_0V8 SOC_I2C2/PM1 0x4B 0.01E
VDA_PLL_1V8_REG VDA_PLL_1V8 SOC_I2C2/PM1 0x4C 0.01E
VDD_PHYIO_1V8_REG VDD_PHYIO_1V8 SOC_I2C2/PM1 0x4D 0.01E
VDA_USB_3V3_REG VDA_USB_3V3 SOC_I2C2/PM1 0x4E 0.01E
SPARE NA SOC_I2C2/PM1 0x4F NA
VDD_MCUIO_1V8_REG VDD_IO_1V8 SOC_I2C2/PM2 0x40 0.01E
VSYS_3V3 VDD_IO_3V3 SOC_I2C2/PM2 0x41 0.01E
VDD_SD_DV_REG VDD_SD_DV SOC_I2C2/PM2 0x42 0.01E
V917_LDO4_1V8 VDD1 SOC_I2C2/PM2 0x43 0.01E
V917_SMPS3_1V1 VDD2 SOC_I2C2/PM2 0x44 0.01E
VDDR_IO_DV_SRC VDDQ_LPDDR4_DV SOC_I2C2/PM2 0x45 0.01E
VDD_MCUIO_1V8_REG VSYS_MCUIO_1V8 SOC_I2C2/PM2 0x46 0.01E
VSYS_3V3 VSYS_MCUIO_3V3 SOC_I2C2/PM2 0x47 0.01E
VDD_MCUIO_1V8_REG VSYS_IO_1V8 SOC_I2C2/PM2 0x48 0.01E
VSYS_3V3 VSYS_IO_3V3 SOC_I2C2/PM2 0x49 0.01E
VCC_12V0 VCC_12V0 SOC_I2C2/PM2 0x4A 0.01E
VSYS_5V0 VSYS_5V0 SOC_I2C2/PM2 0x4B 0.01E
VSYS_3V3 VSYS_3V3 SOC_I2C2/PM2 0x4C 0.01E
VSYS_3V3 VSYS_3V3_SOM SOC_I2C2/PM2 0x4D 0.01E
VDD_EXTLDO1_0V8 VDDA_DLL_0V8 SOC_I2C2/PM2 0x4E 0.01E
EXP_3V3 EXP_3V3 SOC_I2C2/PM2 0x4F 0.01E
