THERMACUT EX-TRAFIRE 105HD - Page 15

EX-TRAFIRE
®
105HD 4 Product description
15
* Nitrogen may be used for cutting stainless steel and Aluminum;
Argon may be used only in connection with the optional marking kit.
Permissible gas Compressed air/Nitrogen/Argon*
Flow rate
100 A/105 A approx. 5.5 CFM
(156 l/Min.) at 70 psi (4.8 bar)
75 A/85 A approx. 3.5 CFM
(101 l/Min.) at 75 psi (5.2 bar)
55A /65A approx. 3.0CFM
(87 l/Min.) at 75 psi (5.2 bar)
45 A approx. 2.9 CFM (82 l /Min.)
at 75 psi (5.2 bar)
Flow rate for gouging
100 A/105 A approx. 7.2 CFM
(205 l/Min.) at 75 psi (5.2 bar)
65 - 85 A approx. 6.8 CFM
(195 l/Min.) at 75 psi (5.2 bar)
Maximum inlet pressure 145 psi (10 bar)
(Dynamic) operating pressure 75 psi (5.2 bar)
Gas post-flow period delay ≥ 25 seconds
Type of voltage DC
Protection type for
EX-TRAFIRE
®
105HD
IP3X (EN 60529)
Connection type TCS (Torch Connection System) –
13 pin
Standard lengths (other lengths
available upon request)
16.5 ft (5 m) / 26 ft (8 m) /
50 ft (15 m) / 75 ft (23 m)
Table 8 Cutting torch weights and cable lengths
Cutting torch Weight and cable lengths
FHT-EX
®
105TTH
Standard hand cutting torch
16.5 ft (5 m) /5.5 lb (2.5 kg)
26 ft (8 m) /7.3 lb (3.3 kg)
50 ft (15 m) /11 lb (5.0 kg)
75 ft (23 m) /17.4 lb (7.9 kg)
FHT-EX
®
105TTM STD-NR
Standard machine torch,
without rack
16.5 ft (5 m) / 5.7 lb (2.6 kg)
26 ft (8 m) / 7.5 lb (3.4 kg)
50 ft (15 m) /12.6 lb (5.7 kg)
75 ft (23 m) / 17.6 lb (8.0 kg)
FHT-EX
®
105TTSM
Short machine torch
16.5 ft (5 m) / 5.7 lb (2.6 kg)
26 ft (8 m) / 7.5 lb (3.4 kg)
50 ft (15 m) /12.6 lb (5.7 kg)
75 ft (23 m) / 17.6 lb (8.0 kg)
Table 7 Technical data for FHT-EX
®
105TTH and FHT-EX
®
105TTM cutting
torches
FHT-EX
®
105TTH /
FHT-EX
®
105TTM
