EX-TRAFIRE
®
105HD 20 Cut charts for mechanized cutting
65
20.7.1 40–45 A cutting, SmoothLine, shielded, with compressed air
EX-5-423-001
EX-5-422-050
EX-5-415-050
EX-5-415-052
EX-5-410-050 EX-5-401-051 EX-5-404-051
Material
thickness
Cut height
(shield to
work cut
height)
Pierce
height
(shield to
workpiece
height)
Pierce
delay time
Recommended speed Kerf width Power supply
Settings for highest
quality
Cutting speed Voltage
[in] [in] [in] [Seconds] [ipm] [Volts] [in] [A]
Mild steel
26 GA
0.079
0.118 0 325 76 0.028
40
24 GA 0.118 0 325 76 0.028
22 GA 0.118 0.1 325 76 0.028
20 GA 0.118 0.2 325 76 0.028
45
16 GA 0.118 0.4 252 76 0.037
14 GA 0.118 0.4 189 80 0.039
12 GA
Edge start
108 83 0.049
3/16 75 85 0.053
Stainless steel
26 GA
0.079
0.118 0 325 70 0.026
40
24 GA 0.118 0 325 70 0.026
22 GA 0.118 0.1 325 70 0.026
20 GA 0.118 0.15 325 70 0.028
45
16 GA 0.118 0.4 242 75 0.028
14 GA 0.118 0.4 170 82 0.035
12 GA
Edge start
82 94 0.043
3/16 35 94 0.043
