Operation
Instrument Controls Menu
3-54 Model 42i Low Source Instruction Manual Thermo Electron Corporation
Instrument Action The Instrument Action screen allows the user to select the instrument state
that is tied to the selected digital input. The selected item is shown by “<--”
after it.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Digital Input Settings > Select Relay > Instrument Action.
• Use and to scroll through a list of choices.
• Press to save the new selection for the relay.
Analog Output Configuration The Analog Output Configuration menu displays a list of the analog output
channels available for configuration. Channel choices include all voltage
channels, all current channels, voltage channels 1-6, and current channels
1-6 (if the I/O expansion board option is installed). Configuration choices
include selecting range, setting minimum/maximum values, and choosing
signal to output.
DIGITAL INPUT SETUP:
>LOGIC STATE OPEN
INSTRUMENT ACTION
RANGE AVG DIAGS ALARM
CHOOSE ACTION:
>NONE
ZERO MODE
SPAN MODE
NO MODE <--
NOX MODE
SET BACKGROUND
CAL TO LO SPAN
ª
RANGE AVG DIAGS ALARM
AOUTS TO ZERO
AOUTS TO FS
CAL TO HI SPAN
