31. ABOUT THE EV-700'S STATE AND INPUT/OUTPUT
Following 3 points are set for the EV-700 as shown in the table below depending on the EV-700's state (Mode
and operation type).
(1) Audio source that can be output
(2) Output destination
(3) Display content in the level meter
EV-700's state Audio source that can be output*
1
Output destination terminal
Display content in
the level meter
Mode
Operation
type
Memory card
audio source
Microphone
input
Line inputs
(Front/Rear)
Line outputs 1
and 2
Headphones
Lock
Standby
−
Input level*
2
of Microphone
input or Line input
Playback *
3
Output level of memory card
audio sources
Input level*
2, 4
of the
Microphone input or Line input
Recording
− −
Input level of the Microphone
input or Line input
Deletion − − − − −
No indication
Playback
Standby
− − − − −
No indication
Playback − −
Output level of memory card
audio sources
Input level*
2, 4
of the
Microphone input or Line input
Monitor playback − − −
Output level of memory card
audio sources
Recording
Standby
− −
Input level of the Microphone
input or Line input
Recording check
Count down
During recording
− *
5
*
5
−
Input level of the Microphone
input or Line input
Monitor playback − − −
Output level of memory card
audio sources
Deletion
Standby
− − − − −
No indication
Deletion check
During deletion
− − − − −
No indication
Monitor playback − − −
Output level of memory card
audio sources
Emergency
Emergency
playback
− −
Output level of memory card
audio sources
R.E.M. playback
(during recording)
− *
5
*
5
−
Input level of the Microphone
input or Line input
R.E.M. playback
(during playback)
− −
Output level of memory card
audio sources
*
1
You can broadcast any one of the memory card audio source, Microphone input, and Line input preferentially
if you set the broadcast priority level. Mixed audio sources cannot be broadcast.
*
2
Output level and input level are the same.
*
3
"Playback in Lock mode" will be made when playback start is triggered by the contact or command in Lock mode.
*
4
Displays the audio source level being broadcast.
*
5
The microphone input or the line input is recorded.
When the microphone and line inputs are simultaneously input, one with the higher broadcast priority assigned
is recorded.
Even if the input having higher-priority broadcast is lost, recording is not switched to the input having lower-
priority broadcast.
