39
Direct control
Program playback
Contact-activated input 1
Contact-activated input 2
P001 playback
P002 playback
P002 start
P001 start
Contact-activated input 1
Contact-activated input 2
Program playback P002 playback
P002 start
P001 start
Contact-activated input 1
Contact-activated input 2
Program playback P001 playbackP002 playback
P002 start
P001 start
12.4.2. Direct control function
[(1) Operation of FIFO (priority setting) playback by a Pulse signal input activation]
• Priority setting: When P001 is higher than P002
(Activation method)
Close the Contact-activated input terminal corresponding to the program number to be played.
(Operation description)
When P001 playback is activated during Program P002 playback, P001 is played preferentially.
• Priority setting: When P001 is lower than or equal to P002
(Activation method)
Close the Contact-activated input terminal corresponding to the program number to be played.
(Operation description)
Even if P001 playback is activated during Program P002 playback, the last-in P001 start is ignored and the
rst activated P002 playback continues.
[(2) Operation of LIFO playback (priority setting) by a Pulse signal input activation]
• Priority setting: When P001 is higher than or equal to P002
(Activation method)
Close the Contact-activated input terminal corresponding to the program number to be played.
(Operation description)
When P001 playback is activated during Program P002 playback, P001 is played preferentially.
