Document Ref 942583-001 Rev 8 Page 5-29
Quantium 510 Installation Manual Installation
2) Lower the dispenser until it sits on the
groundframe.
Note: no risk that the nefit pipes will
collide with the shear valves as it is
inserted deep enough inside the filter
pots
3) Untighten the Nefit nut.
4) Slide down the Nefit pipe.
5) Screw the Nefit pipe into the Shear valve.
6) Tighten the Nefit nut.
