Tokheim Quantium 510 - Four Frames & Three Columns Models (Suction & Submerged) (Ths 4-6, SVHS 4-6)

Document Ref 942583-001 Rev 8
Page 3-21
Quantium 510 Installation Manual Drawings
3.4.6 FOUR FRAMES & THREE COLUMNS MODELS (SUCTION & SUBMERGED) (THS 4-6, SVHS 4-6)
Driptray extent
NOTE : When measuring from the external edge of a factory supplied
groundframe, add 8mm to dimensions referenced from edge of driptray base.
Side A
904 1 48
Prod 1 Prod 2 Diesel Diesel
MODEL THS 4-6
597.5 58
60
112.5
197.5
282.5
400
390
5
00
462
231
943
Empty
Position
*-DISPENSER SIDE A-*
1698.5
60380
693
Mounting Holes
Groundframe
Suction Pipes
*-DISPENSER SIDE B-*
1043
Side B
702.5
864.5
1095.5
1326.5
1557.5
*Satellite A
*Satellite B
597.5
717.5
Vapour Recovery
Electrical
Supply
*For option VR Per Product (Ethanol Split Only) refer to Page 2-29*
