Tokheim Quantium 510 - Four Frames & Four Columns Models (Suction & Submerged) (4-4, 4-8, HS 4-4, HS 4-8, VHS 4-8)

Page 3-22
Document Ref 942583-001 Rev 8
Drawings Quantium 510 Installation Manual
3.4.7 FOUR FRAMES & FOUR COLUMNS MODELS (SUCTION & SUBMERGED) (4-4, 4-8, HS 4-4 , HS 4-8, VHS 4-8)
60
58
387.5
302.5
217.5
1720
1027
880
1258
1489
865
*Satellite A
760
100
110
1861
760
380
1043
943
Side B
Prod Prod Prod Prod
1 2 3 4
Prod Prod Prod Prod
1 2 3 4
MODEL VHS 4-8
Side A
MODELS 4-4, 4-8, HS 4-4, HS 4-8
Vapour Recovery
*Satellite B
Electrical
Supply
Mounting Holes Groundframe
Suction Pipe
*-DISPENSER SIDE A-*
*-DISPENSER SIDE B-*
3x231=693
Driptray extent
Side B
NOTE : When measuring from the external edge of a factory
supplied groundframe, add 8mm to dimensions referenced
from edge of driptray base.
Side A
*For option VR Per Product (Ethanol Split Only) refer to Page 2-29*
