Tokheim Quantium 510 - Two Frames & Two Columns Models (Suction & Submerged) (2-2, 2-4, Hs 2-2, Hs 2-4, Vhs 1-2 Ss, Vhs

Document Ref 942583-001 Rev 8
Page 3-17
Quantium 510 Installation Manual Drawings
3.4.2 TWO FRAMES & TWO COLUMNS MODELS (SUCTION & SUBMERGED) (2-2, 2-4, HS 2-2, HS 2-4, VHS 1-2 SS, VHS
(M)2-4)
NOTE : When measuring from the external edge of a factory
supplied groundframe, add 8mm to dimensions referenced
from edge of driptray base.
Suction Pipe
Mounting Holes Groundframe
Vapour Recovery
*Satellite A
*Satellite B
Electrical
Supply
387.5
60
380
231
387.5
481
581
*-DISPENSER SIDE A-*
100
302.5
217.5
702
933
435
555
540
110
1074
435
*-DISPENSER SIDE B-*
Driptray extent
Prod 1 Prod 2
Side A
Side B
MODEL VHS 1-2 SS, VHS 2-4
Prod 1 Prod 2
MODELS 2-2, 2-4, HS 2-2, HS 2-4
Side A
Side B
58
*For option VR Per Product (Ethanol Split Only) refer to Page 2-29*
