Tokheim Quantium 510 - Satellite (Suction & Submerged)

Document Ref 942583-001 Rev 8
Page 3-25
Quantium 510 Installation Manual Drawings
3.4.10 SATELLITE (SUCTION & SUBMERGED)
60
911.5
272.5
770.5
377.5
Dimensions shown are from the edge of driptray base
581
481
Side A
538
A
Side B
B
822
429
324
424
410
905
995.5
589.7
Dimensions shown are from cladding panels
Electrical
Supply
Side B
Side A
520
450
402
70
500
Edge of
Mounting Holes
Groundframe
For Side A
For Side B
100
58
110
base
