Tokheim Quantium 510 - Mini-Sat

Page 3-26
Document Ref 942583-001 Rev 8
Drawings Quantium 510 Installation Manual
3.4.11 MINI-SAT
130
30
90
230
263
100
260
430
5
2
0
Blind side
Product pipe
Electrical supply
MSAT
MSAT
Mounting holes
Top view
Dimensions shown are from cladding panels
Left Side Nozzle Setup
Top view
Dimensions shown are from driptray
Right Side Nozzle Setup
ground frame
86
= 340 =
= 200 =
MSAT
MSAT
Blind side
Mounting holes
ground frame
