Tokheim Quantium 510 - Four Frames & Four Columns Models (4-4, 4-8, HS 4-4, HS 4-8, VHS 4-8)

Page 3-8
Document Ref 942583-001 Rev 8
Drawings Quantium 510 Installation Manual
3.1.7 FOUR FRAMES & FOUR COLUMNS MODELS (4-4, 4-8, HS 4-4, HS 4-8, VHS 4-8)
Cladding extent (column)
Edge of driptray base
Groundframe extent
Cladding extent (door)
Edge of driptray base
Groundframe extent
DETAIL A
DETAIL B
50
8.0
12
5.0
Cladding extent
(end panel)
Edge of driptray base
Groundframe extent
DETAIL C
33.5
8.0
B SIDE
A SIDE
Groundframe extent
Driptray extent
Cladding extent
SEE DETAIL A
SEE DETAIL B
SEE DETAIL C
Island Level
500
510
520
1861
1877
1944.5
900
1781
