Tokheim Quantium 510 - Basic Model Schematics

Document Ref 942583-001 Rev 8 Page 2-5
Quantium 510 Installation Manual Site Preparation
Prod
1
40
Prod 1
B side (left)
A side (right)
Blind side
In case of NON-preset with TQP-RS, the valves are not needed.
The valve is needed for Preset or in any case of submerge.
Example shown is B sided (left), A sided (right) is also available.
Prod
1
40
40
Prod
1
Prod 1
Prod 1
B side (left)
A side (right)
2.2.1 STANDARD SPEED MODELS
Model 1-1
Model 1-2
2.2 Basic Model Schematics
TQP-RS Pump TQP-HS Pump
TQM Meter Solenoid Control Valve
Non-return valve
(with relief)
