Page 2-4 Document Ref 942583-001 Rev 8
Site Preparation Quantium 510 Installation Manual
Q510 DISPENSER - WINCOR CONFIGURATION
Island Level
Zone 1 Non-hazardous zone
Zone 2
Note:- On this drawing all Zone 2 areas are external of the dispenser.
Zone 1 areas are internal in the dispenser.
Dimensions A and B will depend on dispenser model/number of hoses - refer to Section 3
Hydraulic
housing
Zone 1
Zone
2
Zone
2
Zone
2
Zone
2
Hose
cassette
housing
Zone 1
Calc
Head
1781
Dim B
Dim A
900
50
50
200
200
200
200
520
200
