Document Ref 942583-001 Rev 8 Page 2-3
Quantium 510 Installation Manual Site Preparation
Q510 DISPENSER - TQC-VGA CONFIGURATION
Note:- On this drawing all Zone 2 areas are external of the dispenser.
Zone 1 areas are internal in the dispenser.
Dimensions A and B will depend on dispenser model/number of hoses - refer to Section 3
Zone 1
Non-hazardous zone
Zone 2
50
1781
Dim B
Dim A
900
50
200
200200200
520
Island Level
Zone 1
Zone
2
Zone
2
Zone
2
Zone
2
Zone 1
Hose
cassette
housing
Hydraulic
housing
Calc
Head
