Tokheim Quantium 510 - Three Frames & Three Columns Models (3-3, 3-6, HS 3-3, HS 3-6, VHS 3-6)

Document Ref 942583-001 Rev 8
Page 3-5
Quantium 510 Installation Manual Drawings
3.1.4 THREE FRAMES & THREE COLUMNS MODELS (3-3, 3-6, HS 3-3, HS 3-6, VHS 3-6)
Cladding extent (column)
Edge of driptray base
Groundframe extent
Cladding extent (door)
Edge of driptray base
Groundframe extent
Cladding extent
(end panel)
Edge of driptray base
Groundframe extent
B SIDE
A SIDE
DETAIL A
DETAIL B
DETAIL C
Groundframe extent
Driptray extent
Cladding extent
SEE DETAIL A
SEE DETAIL B
SEE DETAIL C
Island Level
50
8.0
12
5.0
33.5
8.0
500
510
520
900
1781
1467.5
1483.5
1551
