Document Ref 942583-001 Rev 8 Page 5-37
Quantium 510 Installation Manual Installation
Master for Mini Satellite
CABLE LEFT NOZZLE &
BUTTON
(4x1.5mm² PVC cable)
MINI SATELLITE LEFT
VBU
LBU1 LNO1
VBU
CABLE RIGHT NOZZLE
& BUTTON
(4x1.5mm² PVC cable)
RNO1
VBU
RBU1
VBU
MINI SATELLITE RIGHT
TERMINALS
INSIDE JUNCTION
BOX IN MINI-SAT
1 2 3
1 2 3 4 5 6 7 8
1 2 3
4 5 6
1 2 3
4 5 6
1 2 3
Key:-
1 = RN01
2 = RBU1
3 = VBU
4 = LN01
5 = LBU1
6 = VBU
1 2 3
SATELLITE TERMINALS IN
MAINS SECTION OF MAIN
JUNCTION BOX IN MASTER
DISPENSER
941939-005 Rev 1
1 2 3 4 5 6 7 8
