Document Ref 942583-001 Rev 8 Page 2-9
Quantium 510 Installation Manual Site Preparation
Diesel
1
80
Prod
1
40
80
Diesel
1
40
Prod
1
Prod 1 Diesel 1
Diesel 1Prod 1
B side (left)
A side (right)
1.5kW
HS in first column also available.
Diesel
1
80
Prod
1
40
Prod 1 Diesel 1
B side (left)
In case of NON-preset with TQP-RS or TQP-HS, the valves are not needed.
The valve is needed for Preset or in any case of submerge.
Example shown is B sided (left), A sided (right) is also available.
HS in first column also available.
Blind side
A side (right)
Model HS 2-4
Model HS 2-2
Model THS 1-2
Diesel
2
80
80
Diesel
1
Diesel 2
Diesel 1
B side (left)
A side (right)
In case of NON-preset with TQP-RS, the valves are not needed.
The valve is needed for Preset or in any case of submerge.
