Tokheim Quantium 510 - Page 65

Document Ref 942583-001 Rev 8
Page 3-15
Quantium 510 Installation Manual Drawings
3.3 Ground Frames (Cont.)
MODEL CONFIGURATION DRIPTRAY SIZE GROUND FRAME PART NUMBER COMMENTS
SAT 2F1C 901110
MSAT 0F1C 943509
1-1 2F1C 903575-001
1-2 2F1C 903575-001
2-2 2F2C 903575-002
2-4 2F2C 903575-002
3-3 3F3C 903575-004
3-6 3F3C 903575-004
4-4 4F4C 903575-006
4-8 4F4C 903575-006
5-5 5F5C N.A. Use 908219 + 5x901072 + 20x900016-004 + 20x900013-003
5-10 5F5C N.A. Use 908219 + 5x901072 + 20x900016-004 + 20x900013-003
HD 2-2 2F2C 903575-002
HS 5-8 SUBMERGED 5F4C 903575-007
THS1-2 2F1C 903575-001
THS 2-4 3F2C 903575-003
THS 3-6 4F3C 903575-005
VHS 1-1 2F1C 903575-001
VHS 1-2 2F1C 903575-001
VHS 1-2 SS 2F2C 903575-002
VHS 2-4 2F2C 903575-002
VHS 3-6 3F3C 903575-004
VHS 4-4 4F2C N.A. Use 904098 + 4x901072 + 16x900016-004 + 16x900013-003
VHS 4-8 4F4C 903575-006
VHSM 1-1 2F1C 903575-001
VHSM 1-2 2F1C 903575-001
VHSM 4-4 4F2C N.A. Use 904098 + 4x901072 + 16x900016-004 + 16x900013-003
HSM 1-1 2F1C 903575-001
HSM 1-2 2F1C 903575-001
