5-2
5.2 Fuses
Unplug the power cord when replacing
1) Turn the AL-100 off and unplug the power cord from
the power outlet.
2) Rotate the fuse holders counter clockwise
approximately 90 degrees using a coin or a
screwdriver, and the holders will pop out.
3) Pick the holder with fingers and pull it out of the unit.
Another holder should also be pulled out.
4) Check both fuses and replace them if necessary.
A good fuse will have a thin strip of metal from one
end to the other without any noticeable breaks. A
blown fuse will have all or a portion of the metal
melted away inside.
5) Reinsert the fuse holders and turn clockwise to lock
them in place.
