Tomey AL-100 User Manual

3-4
3.2.2 Connecting the option parts
a) Inserting and removing the memory card
Before using memory card for the first time, set the bat-
tery in accordance with the instruction Manual for
Memory Card (located in the box that contains the catd).
Follow the instructions for BN-HSR series.
Since the memory card pops quickly out of the slot when
removed, hold the edge of the card when pressing the but-
ton for card removal.
“Inserting the card”
Hold the front of the memory card (1) toward you and in-
sert it into the slot (2) until the card is aligned with the
removal button.
“Removing the card”
Remove the memory card (1) by pressing the button (2).
DO NOT INSERT or REMOVE the memory card, when
data is loaded from or saved into the memory card.
