Tomey AL-100 User Manual

3-2
3.2 Prepartion before use
3.2.1 Connecting the accessaries
a) Connecting the biometry probe
Connector should be plugged into the terminal with a
proper direction.
Plug the biometry probe connector (1) into the terminal (2)
labeled BIO on the front side of the instrument. When it is
properly insetrted, you will hear it click.
b) Connecting the power cord
Power cord should be plugged into the terminal with a
proper direction.
Plug the power cord connector (1) into the terminal (2) on
the back of the AL-100.
All of 3-Pin in the plug must be connected.
