Tomey AL-100 User Manual

(1) Communication Cable Terminal
The communication cable is connected here.
(2) Power supply terminal
The power cord is connected here.
(3) Fuse holders
Fuses are in use in these holders.
(4) Power switch
Press the “ I ” side of the switch to turn on the power. Press the “ O ” side to turn it off.
(5) Contrast adjuster
Controls the contrast of the screen
(6) Power cord with 3-prong plug
Connection of this cord to a 3-prong power receptacle provides power to the AL-2000.
(7) Meintenance Switch
Switch for Manufacturer’s use only. Do not change its position.
(8) Footswitch Terminal
The footswitch is connected here.
(9) Power supply terminal for chin rest fixation light
The power plug for the fixation light for the chin rest.
2-4
