RS-232C specification for this unit is as shown below.
・ Cable Straight cable supporting for a DOS/V PC
・ Communication method Full duplex
・ Synchronous system Start stop synchronization
・ Baud rate 2400/4800/9600/19200/38400 BPS (Bits Per Second)
・ Bit configuration Data length 7 bits/8 bits
Parity EVEN/ODD/NONE
Stop bits 1 bit/2 bits
・ Communication format ASCII format
・ Delimiter "CR+LF" or "CR" added to the end of communication data strings.
Dip Switch Settings
When connected with a PC, the dip switches should be set as shown below.
Dip switch 1 : REMOTE side
Dib switch 2 : Either the RS-232C side or USB side depending on the connection method
used
When the power is turned ON in this state, the instrument will warm up for 10 minutes, then the
instrument enter the remote mode and the following screen will be displayed.
Turning on the Power
☞
「1.3.4 Turning ON/OFF the Power」
Ｒｅｍｏｔｅ Ｍｏｄｅ
Ｗａｒｍ－ｕｐ．．． Ｖｅｒ．１．００
