4. Communication With a PC
64
4.2.6 MM Command
The measurement range of the instrument is changed to the MANUAL mode.
Sets the X
２
,Y and Z setting ranges.
MM‗X[l]‗Y[m]‗Z[n] : l is the measurement range for X 1 to 5
m is the measurement range for Y 1 to 5
n is the measurement range for Z 1 to 5
"‗" indicates a space.
PC Command BM-7A
MM‗X3‗Y3‗Z3 + (Cr･Lf)
OK + (Cr･Lf)
4.2.7 FR Command
The correction factor currently being used by the instrument are read out.
PC Command BM-7A
FR + (Cr･Lf)
OK + (Cr･Lf)
Correction factor number
END + (Cr･Lf)
4.2.8 F Command
The correction factor currently to be applied to the instrument are stored the instrument.
F [n] : n is the number of the correction factor to be currently being used. 0 to 15
PC Command BM-7A
F15 + (Cr･Lf)
OK + (Cr･Lf)
