3. Various Settings
54
3.7.1 Setting an Area Correction Factor
The procedure for changing the setting for an area correction factor group is as described below.
1
Press the [CHANGE] button.
The currently set area correction group is displayed.
2
Press the [ROTATION] button and select the setting contents.
3
After selection is finished, press the [ENTER] button.
3.7.2 Displaying an Area Correction Factor
The procedure for displaying the chromaticity area that is set for an area correction factor group
is as described below.
1
Press the [CHANGE] button.
The currently set area correction group is displayed.
2
Press the [ROTATION] button, and select the area correction factor group for which the
chromaticity area is to be displayed.
3
Press the [CHANGE] button.
The data of the set chromaticity area is displayed.
[CHANGE] : Sets the displayed chromaticity area.
When set, "SET" is displayed underneath the number of the chromaticity
area.
[ROTATION] : Displays the chromaticity area of the next number.
[SHIFT] : Each time the button is set, the display changes as shown below.
Correction factor data → Chromaticity area data → Correction factor
data …
[ENTER] : Returns to the previous screen.
ＧＲＯＵＰ ＳＥＴ
ＧＲＯＵＰ ＊ＯＦＦ
ＧＲＯＵＰ ＳＥＴ
ＧＲＯＵＰ ＊ＯＦＦ
Ｇ１－１ ｘ０．２０００－０．２３００
ＳＥＴ ｙ０．３０００－０．３３００
Ｌ１．０００Ｅ＋０２
Ｃ＝ＳＥＴ Ｒ＝ＮＥＸＴ Ｓ＝ＰＡＧＥ
