3. Various Settings
55
3.8 Measurement Range
When using the manual range, the measurement range for X
2
, Y, and Z is displayed.
Display Method
☞
「3.1.2 Data/Setting Item Display」
The procedure for making changes is as described below.
1
Press the [CHANGE] button.
It is no possible to select the value for X
2
.
2
Press the [ROTATION] button and select the setting contents
3
After setting is completed, press the [ENTER] button.
Now, the value for Y can be selected, so similarly select the value for Y and Z.
・ The measurement range is from 1 to 5, with range 1 having the maximum sensitivity.
Measurement Range Details
☞
「Appendix: Specifications」
・ When the AUTO/MANU switch is set to AUTO, and dip switch 1 is set to the remote side,
the measurement range setting is invalid.
・ The factory settings for X
2
, Y and Z are all range 3.
・ After selecting Z, press the [ENTER] button. The next setting item (screen) is displayed.
＊ Ｍｅａｓｕｒｉｎｇ ｒａｎｇｅ ＊
Ｘ２:Ｒａｎｇｅ１
Ｙ :Ｒａｎｇｅ３
Ｚ :Ｒａｎｇｅ３
Memo
