2. Measurement Operation
33
2.2 Absolute Value Measurement
The procedure for absolute value measurement is described below.
1 Set dip switch 4 to the ABS side.
2 Press the RUN/HOLD switch.
The panel switch [RUN] blinks and continuous measurement starts.
3 To end measurement, press the RUN/HOLD switch.
The panel switch [HOLD] blinks, and the measurement result is displayed.
Ｆ２．０ ＡＢＳ Ｋ００ Ｇ００－０
ｘ＝ ０．１９３０
ｙ＝ ０．４８９９
Ｌ＝ ３．０１６Ｅ＋０１ ｃｄ／ｍ＾２
