Topcon HiPer Ga User Manual

Receiver and File Maintenance
HiPer Ga/Gb Operator’s Manual
5-20
5. Click the Device tab, and set the Device Type as “Receiver’s
Power Board.” Click Get from Device for device information
(Figure 5-21).
Figure 5-21. Set Device Type
6. Click the Program tab, and set the Capture Method to “Soft
Break Capture” (recommended) (Figure 5-22).
Figure 5-22. Program Tab Settings
7. Browse for and select the Power board’s RAM file (Figure 5-22).
8. Click Load, and wait until 100% of the power board file loads
into the receiver.
NOTICE
If you selected an incorrect file, an error message
displays at the bottom of the dialog box. Select the
correct file.
